Features
- Powerful, robust compressor for simple, commercial use
- Oil-free piston compressor: simple transportation and reduced service requirements
- For single phase alternating current
- Operating pressure can be regulated according to application by means of a pressure reducer and manometer
- Convenient pressure switch for good cold starting, complete with relief valve
- Overload protection: protects the motor from overheating
- Rubberised, stable wheels for mobile use
- Additional manometer for displaying the tank pressure
- Rubber-coated handle for comfortable handling
Technical Information
- Suction rate220 l/min / 7.8 cfm
- Filling capacity120 l/min / 4.2 cfm
- Effective delivery volume (at 80% max. pressure)100 l/min / 3.5 cfm
- Maximum pressure8 bar / 116 psi
- Rated input power1.5 kW / 2 HP
- Maximum speed2850 rpm
- Tank capacity24 l / 6.3 gal
- Sound pressure level (LPa)82 dB(A)
- Sound power level (LWA)97 dB(A)
- Dimensions620 x 340 x 580 mm // 24 13/32 x 13 3/8 x 22 27/32 “
- Weight24 kg / 53 lbs
- Cable length1.5 m / 5 ft
- Sound pressure level82 dB(A)
- Sound power level (LWA)97 dB(A)
